描述
特點和優點
4K解析度互動顯示
- 提供大屏觀看體驗
高精度觸控體驗
- 直覺的 20 個觸控點
- 抗光學幹擾（在陽光直射下照常使用）
- 反應快速，文字流暢，示範流暢
耐用的白板表面
- AG強化玻璃莫氏7級
多作業系統+多模組
- 作業系統間無縫切換
- 內建Android+可插拔PC模組
- 隱藏式WIFI模組，相容於WIFI 6網絡
額外資訊
Specification: FUJITSU IW862 Pro 互動觸控屏幕
| Projectors | ||
|---|---|---|
|
||
| Monitors | ||
|
||
Technical Details
| Product Name | Interactive Panel IW862 Pro |
|---|---|
| Picture Performance | |
| Panel and backlit | DLED |
| Screen Surface Treatment | AG tempered glass Mohs level 7 |
| Contrast – typical | 1200:1 |
| Viewing angle (h/v) – typical | 178° |
| Color performance | 1.07 Billion Colors |
| Brightness – typical | 350 cd/m²(Typ) |
| Size and Resolution | |
| Aspect ratio | 16:09 |
| Resolution (native) | 3840(H) x 2160(V) |
| Picture Size (H x V) | 1,895.04 x 1,065.96 mm |
| Pixel Pitch | 0.4935 mm |
| Response Time | 8ms(Typ) |
| Refreshing Frequency | 60Hz |
| Connectivity | |
| VGA/D-SUB | 1 x D-SUB |
| HDMI | 1 x HDMI OUT (4K), 3 x HDMI IN (HDMI 2.0) |
| USB | 1 x USB 2.0 4 x USB 3.0 (including 2 USB ports in front) |
| USB Type-C™ | 1 x USB Type-C™ |
| Audio In | 1 x 3.5 mm stereo phone jack |
| Audio output | 1 × Audio out |
| Built-in Speaker | Yes, 2 x 16 W |
| RS232 Control | 1 x RS232 |
| LAN IN | 1 x GIGABIT LAN (RJ45) |
| LAN OUT | 1 x GIGABIT LAN (RJ45) |
| TOUCH OUT | 2 x TOUCH OUT (USB 3.0) |
| SPDIF | 1 × SPDIF |
| Bluetooth | Yes |
| Touch System | |
| Sensing Type | Infrared recognition |
| Touch point | 20 points touches, 10 points writing |
| Touch Tool | Finger / Passive infrared pen / Active infrared pen |
| Response Time | <10ms |
| Accuracy | ±1 mm (over 90% area) |
| Communication Mode | Full-speed USB (driver free) |
| Wireless Screen Mirroring | |
| Wireless Screen Mirroring | Supports |
| Self-Hotspot Screen Mirroring | Supports |
| Native AirPlay protocol for screen mirroring |
Supports |
| Native Chromecast protocol for screen mirroring |
Supports |
| Power consumption (Typical) | |
| Soft switch off | ≤0.5W |
| Overall Power(nominal power) | 650 W |
| Electrical values | |
| Rated voltage range | 100 V – 240 V |
| Rated frequency range | 50 Hz – 60 Hz, 6.5 A |
| Quality and Reliability | |
| MTBF (demonstrated) | 50,000h |
| Dimensions / Weight / Environmental | |
| Key Location & Number | Front physical keys, 1 |
| Dimension (L x H x D) | 1,957 x 1,159 x 86 mm |
| Dimension(package) LxWxH | 2,110 x 225 x 1,283 mm |
| Net Weight | 64.6 kg |
| Gross Weight | 82.28 kg |
| Thickness of machine and wall mount | 116 mm (9,060G) |
| Wall-hanging Screw Spec | M8 x 25 mm |
| VESA | 800 x 600 mm |
| Miscellaneous | |
| Color | Black |
| Clock & Time | Manual/ automatically synchronize with server |
| Accessories | |
| AC Power Cable | British Standard Power Cord (3 meters), EU Power Cord (3 meters) |
| USB Cable | 1, 5 meters, USB 2.0 |
| HDMI cable | 1, 3 meters |
| Writing Pen | 2 |
| Remote Control | 1 |
| Operation Instruction | 1 |
| Warranty | |
| Standard warranty | 1 year (depending on country) |
