AOV IWB-AT86F 86吋
Interactive WhiteBoard
Simplify the work and life with smart technology for your business enhanced the full potential to success
• 40 Touch Points
• 4K UHD (3840*2160) Resolution
• LG 4K LED Panel
• 1.07 Billion Colors
• 1600:1 Contrast
• 178° Viewing Angle
• 4mm Thickness Mohs-7 level Anti-Glare Glass
• Supports Windows; Mac; Linux; Chrome OS
Special Note:
Due to the impact of the epidemic on the global supply chain and logistics, some models are out of stock or delayed delivery. In order to avoid disappointment and reduce the work of both parties, please consult the quantity and delivery date before placing an order.
Inquire about this product now
Click on the icon to contact us via Whatsapp with the name of this product.
名稱：IWB_Guide_EN.pdf
IWB_Guide_EN.pdf
AOV IWB-AT86F 86吋
Original price was: $39,800.00.$29,800.00Current price is: $29,800.00.
Description
Interactive WhiteBoard
Simplify the work and life with smart technology for your business enhanced the full potential to success
• 40 Touch Points
• 4K UHD (3840*2160) Resolution
• LG 4K LED Panel
• 1.07 Billion Colors
• 1600:1 Contrast
• 178° Viewing Angle
• 4mm Thickness Mohs-7 level Anti-Glare Glass
• Supports Windows; Mac; Linux; Chrome OS
Flexible, Smooth And Accurate Interaction
Supports multitouch to 40 points creating the interactive environment for presentation and teaching activities.
Ultra High Definition
Interactive Flat Panel Display are HDR-enabled across all models. 3840 x 2160 resolution enhances the dynamic range of picture.
Specification:
| Model | IWB-AT85F |
|---|---|
| Display Specification | |
| Diagonal Display Size | 86″LED Backlight |
| Panel | LG 4K LED Panel |
| Active Area (mm) | 1913.0(H) x 1084.0 (V) |
| Resolution | 3840*2160 |
| Pixel Pitch | 0.429 mm x 0.429 mm |
| Bock Light | Direct Type LED |
| Aspect Ratio | 16:9 |
| Controst Ratio | 1600:1 |
| Colors | 1.07 Billion Colors |
| Brigh tness | 350cd/m2 |
| Viewing Angle | 178° |
| Screen Surface | |
| Touch System | |
| Technology | IR Touch |
| HID Support | Yes |
| Touch Supported | 40 Touch Points |
| Writing Tools | Pen Or Finger |
| Response Time | 7ms |
| Cursor Speed | 125Points/s |
| Precision | 3mm |
| Connectivity | |
| Front Side | |
| RS232 1-Line, MIC IN 1-Line, TF IN 1-Line, USB 2.0 Media 2-Line, HDMI IN – 3 Lines(1Line For OPS PC), SPDIF OUT 1-Line, AV IN 1-Line, AV OUT1- Line, EARPHONE 1-Line, VGA IN 1-Line, AUDIO IN 1-Line, RJ45 LAN 1 Line, YPBPR 1-LineRS232 1-Line, MIC IN 1-Line, TF IN 1-Line, USB 2.0 Media 2-Line, HDMI IN – 3 Lines(1 Line For OPS PC), SPDIF OUT 1-Line, AV IN 1-Line, AV OUT 1-Line, EARPHONE 1-Line, VGA IN 1-Line, AUDIO IN 1-Line, RJ45 LAN 1 Line, YPBPR 1-LineRS232 1-Line, MIC IN 1-Line, TF IN 1-Line, USB 2.0 Media 2-Line, HDMI IN – 3 Lines(1 Line For OPS PC), SPDIF OUT 1-Line, AV IN 1-Line, AV OUT1- Line, EARPHONE 1-Line, VGA IN 1-Line, AUDIO IN 1-Line, RJ45 LAN 1 Line, YPBPR 1-Lline | |
| Outputs (Speakers) | |
| Operating System | |
| Android Version | |
| CPU | |
| GPU | |
| RAM | |
| ROM | |
| Compliant With | |
| Integrated Windows Standard OPS PCCOptional) | |
| Windows OPS PC Slot | |
| Electrical | |
| Input Voltage | 100-240V AC |
| Power Requirement | Yes |
| Power Consumption (Standby) | <0.5W |
| Power Consumption | Maximun< 360W Eco<75W |
| Physical Specifications | |
| Net Weight (kg±2) | 75 |
| Gross Weight (kg±2) | 105 |
| Dimension(W*D*H) mm | 1989*107*1207 |
| VESA(mm) | 800*600 |
| Accessories | |
| Software And Manuel CD, IWB Pen Without Ink 2pcs, Remote Control, 1.5m Power Cable, 1.5m HDMI Cable, 3m USB Extension Coble, 1.5m HDMI Cable, Wall Bracket | |
Additional information
Specification: AOV IWB-AT86F 86吋
|
| Model | IWB-AT55F | IWB-AT65F | IWB-AT75F | IWB-AT86F |
|---|---|---|---|---|
 |
 |
 |
 |
|
| Display Specification | ||||
| Diagonal Display Size | 55″ LED Backlight | 65″ LED Backlight | 75″LED Backlight | 86″LED Backlight |
| Panel | LG4K LED Panel | LG 4K LED Panel | LG4K LED Panel | LG 4K LED Panel |
| Active Area (mm) | 1209(H)x680(V) | 1428.48 (H) x 803.52 (V) | 1650.24(H)x928.26(V) | 1913.0(H) x 1084.0 (V) |
| Resolution | 3840*2160 | 3840*2160 | 3840*2160 | 3840*2160 |
| Pixel Pitch | 0.372mm x 0.372mm | 0.372mm x 0.372mm | 0.429 mm x 0.429 mm | 0.429 mm x 0.429 mm |
| Bock Light | Direct Type LED | Direct Type LED | Direct Type LED | Direct Type LED |
| Aspect Ratio | 16:9 | 16:9 | 16:9 | 16:9 |
| Controst Ratio | 1600:1 | 1600:1 | 1600:1 | 1600:1 |
| Colors | 1.07 Billion Colors | 1.07 Billion Colors | 1.07 Billion Colors | 1.07 Billion Colors |
| Brigh tness | 350cd/m2 | 350cd/m2 | 350cd/m | 350cd/m2 |
| Viewing Angle | 178° | 178° | 178° | 178° |
| Screen Surface | 4mm Thickness Mohs-7 level Anti-Glare Glass | |||
| Touch System | ||||
| Technology | IR Touch | IR Touch | IR Touch | IR Touch |
| HID Support | Yes | Yes | Yes | Yes |
| Touch Supported | 40 Touch Points | 40 Touch Points | 40 Touch Points | 40 Touch Points |
| Writing Tools | Pen Or Finger | Pen Or Finger | Pen Or Finger | Pen Or Finger |
| Response Time | 7ms | 7ms | 7ms | 7ms |
| Cursor Speed | 125Points/s | 125Points/s | 125Points/s | 125Points/s |
| Precision | 3mm | 3mm | 3mm | 3mm |
| Connectivity | ||||
| Front Side | HDMI IN 1-Line, USB 2-Line, USB For Touch 1-Line | |||
| RS232 1-Line, MIC IN 1-Line, TF IN 1-Line, USB 2.0 Media 2-Line, HDMI IN – 3 Lines(1Line For OPS PC), SPDIF OUT 1-Line, AV IN 1-Line, AV OUT1- Line, EARPHONE 1-Line, VGA IN 1-Line, AUDIO IN 1-Line, RJ45 LAN 1 Line, YPBPR 1-LineRS232 1-Line, MIC IN 1-Line, TF IN 1-Line, USB 2.0 Media 2-Line, HDMI IN – 3 Lines(1 Line For OPS PC), SPDIF OUT 1-Line, AV IN 1-Line, AV OUT 1-Line, EARPHONE 1-Line, VGA IN 1-Line, AUDIO IN 1-Line, RJ45 LAN 1 Line, YPBPR 1-LineRS232 1-Line, MIC IN 1-Line, TF IN 1-Line, USB 2.0 Media 2-Line, HDMI IN – 3 Lines(1 Line For OPS PC), SPDIF OUT 1-Line, AV IN 1-Line, AV OUT1- Line, EARPHONE 1-Line, VGA IN 1-Line, AUDIO IN 1-Line, RJ45 LAN 1 Line, YPBPR 1-Lline | ||||
| Outputs (Speakers) | 15W*2 | |||
| Operating System | ||||
| Android Version | 6.0 | |||
| CPU | Cortex A53*4 1.5GHz | |||
| GPU | T720MP2 | |||
| RAM | 2G | |||
| ROM | 32G | |||
| Compliant With | Windows； Mac； Linux; Chrome OS | |||
| Integrated Windows Standard OPS PCCOptional) | ||||
| Windows OPS PC Slot | Yes | |||
| Electrical | ||||
| Input Voltage | 100-240V AC | 100-240V AC | 100-240V AC | 100-240V AC |
| Power Requirement | Yes | Yes | Yes | Yes |
| Power Consumption (Standby) | <0.5W | <0.5W | <0.5W | <0.5W |
| Power Consumption | Maximun< 180W Eco<75W | Maximun< 220W Eco<75W | Maximun< 300W Eco<75W | Maximun< 360W Eco<75W |
| Physical Specifications | ||||
| Net Weight (kg±2) | 35 | 45 | 60 | 75 |
| Gross Weight (kg±2) | 44 | 58 | 80 | 105 |
| Dimension(W*D*H) mm | 1291*102*808 | 1522*107*944 | 1744*107*1069 | 1989*107*1207 |
| VESA(mm) | 400*400 | 600*400 | 600*400 | 800*600 |
| Accessories | ||||
| Software And Manuel CD, IWB Pen Without Ink 2pcs, Remote Control, 1.5m Power Cable, 1.5m HDMI Cable, 3m USB Extension Coble, 1.5m HDMI Cable, Wall Bracket | ||||
